DW-12S
DIKKWELL
| Quantity: | |
|---|---|
KEY POINTS
3 cylinder engine, sufficient engine power, can be configured with a variety of accessories.
Using Japan original imported main valve, exclusive valve core, soft action.
Using two-speed walking motor, can automatically switch according to load changes single-speed.
Rotary motor large displacement, torque, to meet the needs of slope operation.
4.3 inch color display, Provide engine speed, working hours, various alarm information
Parameter | DW-12S |
Operating weight(kg) | 1200 |
Engine type | Kubota D782 |
Engine power(kW/rpm) | 9.8/2300 |
Bucket capacity(m³) | 0.022 |
External dimensions(mm) | 3025*830/1000*2260 |
Bucket rod digging force(kN) | 5.4 |
Bucket digging force(kN) | 10.4 |
Rotating speed(r/min) | 11 |
Travel speed(km/h) | 2/3.5 |
Maximum digging height(mm) | 3017 |
Maximum digging distance(mm) | 3360 |
Maximum digging depth(mm) | 1800 |
Emissions (Indicated as per international standards) | EU stage V |
