DW-17S
DIKKWELL
| Quantity: | |
|---|---|
KEY POINTS
DW-17S with OPG/TOPS canopy (cab) provides excellent visibility, stability, optimal comfort, and safety. For tough jobs in tight corners that demand precision control and state-of-the-art performance.
DW-17S is ready to work, offering following advanced features: Zero-tail swing, hydraulic retractable undercarriage, boom swing, foldable dozer blade. Featuring high reliability, low operating cost, and superior efficiency, and you’ve got the ideal mini for a wide range of modern jobs.
Extended Undercarriage, With the standard hydraulic retractable undercarriage passing through a narrow doorway or gate is easy. Extended undercarriage provides the operator better stability, lifting and loading performance.
Foldable blade, through two pin shafts, the dozer blade can be folded and expanded easily. In a confined space, the blade width can be adjusted arbitrarily, which makes the construction much easier.
This machine is built around the operator – providing optimal ergonomics for operators of all sizes. Access to the seat is convenient thanks to the large entry.
Easy service access, with a single access point for the daily maintenance of all main components, fuel level gauge and refueling through the lockable cap.
Parameter | DW-17S |
Operating weight(kg) | 1880 |
Engine type | Kubota D902 |
Engine power(kW/rpm) | 11.8/2300 |
Bucket capacity(m³) | 0.04 |
External dimensions(mm) | 3575*1300*2405 |
Bucket rod digging force(kN) | 9.5 |
Bucket digging force(kN) | 16 |
Rotating speed(r/min) | 9.5 |
Travel speed(km/h) | 2.2/4.3 |
Maximum digging height(mm) | 3535 |
Maximum digging distance(mm) | 3910 |
Maximum digging depth(mm) | 2270 |
Emissions (Indicated as per international standards) | EU stage V/T4F |
